- Joining plates for connection of two profiles with a defined angle
| Designation | Value |
|---|---|
| B | 110.0 mm |
| A | 70.0 mm |
| C | 40.0 mm |
| F | 9.7 mm |
| E | 3.0 mm |
| G | 50.0 mm |
Here you will find all available documents, such as data sheets, certificates, and much more.
| File | Filesize | Actions |
|---|---|---|
| datasheet-bds-fipa-gr01-063-eckverbinder-90-130-en-master.pdf | 538.28 KB | Download |
Here you can find all documents about this product.
